| Physical Characteristics |
Dimensions |
Corded: 7.3 in H × 3.0 in W × 5.2 in D (18.5 × 7.6 × 13.2 cm)
Cordless: 7.3 in H × 3.0 in W × 5.6 in D (18.5 × 7.6 × 14.2 cm)
|
| Weight |
Corded: 10.9 oz / 309 g
Cordless: 14.5 oz / 411 g
|
| Input Voltage |
Host powered: 4.5 VDC min – 5.5 VDC max
External power supply: 11.4 VDC min – 12.6 VDC max
|
| Operating Current |
DS3608-HD (corded): 360 mA (RMS typical) |
| Standby Current |
DS3608-HD (corded): 100 mA (RMS typical) |
| Color |
Industrial Green |
| Supported Interfaces |
USB, RS232, Keyboard Wedge
Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Standard TCP/IP
|
| Battery |
Battery Type |
PowerPrecision+ 3100 mAh Li-Ion rechargeable battery |
| User Indicators |
Direct decode indicator, LEDs, beeper, vibration |
| Performance Characteristics |
Scans per Charge |
100,000+ scans |
| Image Capture |
Basic |
| Illumination |
Two warm white light LEDs |
| Aimer |
655 nm laser |
| Field of View |
Horizontal: 31°
Vertical: 23° |
| Image Sensor |
1280 × 960 pixels |
| Minimum Print Contrast |
15% reflective difference |
| Scan Angles |
Skew |
±60° |
| Pitch |
±60° |
| Roll |
±360° |
| Wireless Connectivity |
Bluetooth |
Bluetooth Class 1, Version 4.0 (LE), SPP and HID profiles |
| Data Rate |
Classic Bluetooth: 3 Mbit/s (2.1 Mbit/s)
Low Energy: 1 Mbit/s (0.27 Mbit/s)
|
| Radio Range |
Class 1: Up to 300 ft (100 m)
Class 2: Up to 30 ft (10 m)
|
| Decode Capabilities |
1D |
Code 39, Code 128, Code 93, Codabar, Code 11,
MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5,
GS1 DataBar, Base 32
|
| 2D |
PDF417, MicroPDF417, Composite Codes,
Aztec, DataMatrix, MaxiCode, QR Code,
Micro QR, Han Xin, Postal Codes
|
| Decode Ranges |
Code 128 (3 mil) |
2.0 – 3.0 in (5.1 – 7.6 cm) |
| Code 128 (20 mil) |
2.2 – 26.0 in (5.6 – 66 cm) |
| DataMatrix (10 mil) |
1.0 – 9.0 in (2.5 – 22.9 cm) |
| PDF417 (5 mil) |
2.0 – 6.0 in (5.1 – 15.2 cm) |
| User Environment |
Operating Temperature |
Corded: -30°C to 50°C (-22°F to 122°F)
Cordless: -20°C to 50°C (-4°F to 122°F)
|
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Humidity |
5% to 95% non-condensing |
| Tumble Specification |
7500 tumbles at 1.0 m |
| Drop Specification |
DS36X8: Multiple 3 m drops to concrete
DS3678: Multiple 2.4 m drops (-20°C to 50°C)
DS3608: Multiple 2.4 m drops (-30°C to 50°C)
|
| Sealing |
Scanner: IP65 & IP68
Cradle: IP65 |
| ESD |
±25 kV air, ±10 kV direct, ±10 kV indirect |
| Ambient Light |
0 – 108,000 Lux (direct sunlight) |
| Utilities & Maintenance |
123Scan |
Scanner configuration, firmware updates and barcode data reporting |
| Scanner SDK |
Drivers, test utilities and sample source code |
| Scanner Management Service |
Remote scanner management and asset information |
| Network Connect |
Direct connection to Industrial Ethernet network |
| Warranty |
Warranty |
3 Years |
